Allosun EM6182 Digital Multimeter

FOB Reference Price:Get Latest Price
  • >=100 Pieces
    $31.00
Lead Time:
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 45 Negotiable
Customization:
Customized logo (Min. Order: 400 Pieces)
Customized packaging (Min. Order: 400 Pieces)

More

Graphic customization (Min. Order: 400 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China
Brand Name:
allosun
Model Number:
EM6182
Dimensions:
184*89*62
Operating Temperature:
0-40℃
Measuring Current Range:
0.1uA-20A
Measuring Voltage Range:
1mV-1000V
Measuring Resistance Range:
0.1Ω-60MΩ
Measuring Capacitance Range:
0.01nF-1000uF
Measuring Inductance Range:
NA
Frequency:
9.999Hz~9.999MHz
Temperature:
-20~1000℃
Supply Ability
Supply Ability:
5000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
paper box
Port
Xiamen
Lead Time :
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 45 To be negotiated
Product Description





SPECIFICATION

Accuracy is specified for a period of 1 year after calibration at 18℃ to 28℃, with relative humidity up to 75%.

Accuracy specifications take the form of: ± [(% of Reading) + (Number of Least Significant Digits)]



DC Voltage

     Range

Resolution

     Accuracy

   600.0mV

0.1mV

± (0.8% + 5)

  6.000V

1mV

± (0.5% + 5)

        60.00V

10mV

  600.0V

0.1V

  1000V

 1V

± (1.0% + 5)



AC Voltage

               Range

  Resolution

     Accuracy

  6.000V

1mV

± (0.8% + 5)

        60.00V

 10mV

  ± (1.0% + 5)

  600.0V

 0.1V

  1000V

1V

± (1.2% + 5)

            DC Current


  Range

  Resolution

Accuracy

  600.0μ A

 0.1μ A

± (1.0% + 7)

   6000μ A

 1.0μ A

 60.00mA

 0.01mA

 600.0mA

 0.1mA

6.000A

1mA

± (1.5% + 7)

20.00A

10mA
